NUD3048MT1G
| Part No | NUD3048MT1G |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | IC PWR SWITCH N-CHAN 1:1 6TSOP |
| Lead Free Status / RoHS Status | Lead Free / RoHS compliant |
| Availability:7512 pcs | |||||
| Quantity | Unit Price | Ext. Price | |||
|---|---|---|---|---|---|
| 1+ | $12.0 | $1200 | |||
| 10+ | $11.76 | $5880 | |||
| 100+ | $11.4 | $1,1400 | |||
| 1000+ | $11.04 | $1,1040 | |||
| 10000+ | $10.56 | $1,0560 | |||
| The above prices does not include taxes and freight rates, which will be calculated on the order pages. | |||||
Specifications
Data sheet
| Transistor Element Material | SILICON |
|---|---|
| Output Type | N-Channel |
| Transistor Application | SWITCHING |
| Output Configuration | Low Side |
| Surface Mount | YES |
| Terminal Finish | Tin (Sn) |
| Drain to Source Voltage (Vdss) | 100V |
| Drain to Source Resistance | 720mOhm |
| Terminal Position | DUAL |
| Package / Case | SOT-23-6 Thin, TSOT-23-6 |
| Lifecycle Status | LAST SHIPMENTS (Last Updated: 3 days ago) |
| Terminal Form | GULL WING |
| Number of Pins | 6 |
| Number of Terminations | 6 |
| Operating Mode | ENHANCEMENT MODE |
| Number of Elements | 1 |
| ECCN Code | EAR99 |
| Lead Free | Lead Free |
| Qualification Status | Not Qualified |
| Pbfree Code | yes |
| RoHS Status | RoHS Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Drain to Source Breakdown Voltage | 100V |
| Gate to Source Voltage (Vgs) | 15V |
| Current Rating | 700mA |
| Switch Type | General Purpose |
| Ratio - Input:Output | 1:1 |
| Mounting Type | Surface Mount |
| Rds On (Typ) | 600m Ω |
| JESD-609 Code | e3 |
| Pin Count | 6 |
| Number of Outputs | 1 |
| Time@Peak Reflow Temperature-Max (s) | 40 |
| Max Operating Temperature | 150°C |
| Peak Reflow Temperature (Cel) | 260 |
| Power Dissipation | 1.56W |
| Continuous Drain Current (ID) | 1.2A |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| FET Technology | METAL-OXIDE SEMICONDUCTOR |
| Published | 2007 |
| Interface | On/Off |
| Max Output Current | 700mA |
| Base Part Number | NUD3048 |
| Voltage - Rated DC | 100V |
Introduce
We can supply NUD3048MT1G , send us a request quote to request NUD3048MT1G pirce and lead time.Wisdom Mobility is a professional electronic components distributor. With 10+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number NUD3048MT1G.The price and lead time for NUD3048MT1G depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part NUD3048MT1G.We look forward to working with you to establish long-term relations of cooperation
