BD7755RFV-E2
| Part No | BD7755RFV-E2 |
|---|---|
| Manufacturer | LAPIS Semiconductor |
| Description | IC MOTOR DRIVER PAR 54HTSSOP |
| Lead Free Status / RoHS Status | Lead Free / RoHS compliant |
| Availability:18491 pcs | |||||
| Quantity | Unit Price | Ext. Price | |||
|---|---|---|---|---|---|
| 1+ | $5.5186 | $552 | |||
| 10+ | $5.4082 | $2704 | |||
| 100+ | $5.2427 | $5243 | |||
| 1000+ | $5.0771 | $5077 | |||
| 10000+ | $4.8564 | $4856 | |||
| The above prices does not include taxes and freight rates, which will be calculated on the order pages. | |||||
Specifications
Data sheet
| Applications: | DC Motors, General Purpose, Stepper Motors |
|---|---|
| Supplier Device Package: | 54-HTSSOP-B |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Voltage - Supply: | 4.3 V ~ 5.5 V, 10.8 V ~ 13.2 |
| Interface: | Logic |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Manufacturer Standard Lead Time: | 9 Weeks |
| Email: | sale@wisdommobility.com |
| Features: | - |
| Operating Temperature: | -20°C ~ 150°C (TJ) |
| Fault Protection: | Over Temperature |
| Output Configuration: | Half Bridge (19) |
| Package / Case: | 54-VSOP (0.295", 7.50mm Width) Exposed Pad |
| Mounting Type: | Surface Mount |
| Packaging: | Tape & Reel (TR) |
| Current - Output / Channel: | 500mA, 1A |
| Load Type: | Inductive |
| Detailed Description: | Half Bridge (19) Driver DC Motors, General Purpose, Stepper Motors Bipolar, Power MOSFET 54-HTSSOP-B |
| Voltage - Load: | - |
| Series: | - |
| Current - Peak Output: | - |
| Base Part Number: | BD7755 |
| Other Names: | BD7755RFV-E2-ND BD7755RFV-E2TR BD7755RFVE2 |
| Technology: | Bipolar, Power MOSFET |
| Rds On (Typ): | - |
Introduce
We can supply BD7755RFV-E2 , send us a request quote to request BD7755RFV-E2 pirce and lead time.Wisdom Mobility is a professional electronic components distributor. With 10+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number BD7755RFV-E2.The price and lead time for BD7755RFV-E2 depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part BD7755RFV-E2.We look forward to working with you to establish long-term relations of cooperation
