AV3602619
| Part No | AV3602619 |
|---|---|
| Manufacturer | Panasonic Electric Works |
| Description | - |
| Lead Free Status / RoHS Status | Contains lead / RoHS compliant |
Specifications
Data sheet
| Operating Temperature | -25u00b0C ~ 85u00b0C |
|---|---|
| Operating Position | 0.330" (8.4mm) |
| Ingress Protection | - |
| Release Force | 7.546gf |
| Termination Style | PC Pin |
| Actuator Type | Round (Pin Plunger) |
| Current Rating (Amps) | 100mA (AC/DC) |
| Circuit | SPDT |
| Mounting Type | Through Hole, Right Angle |
| Mechanical Life | 500,000 Cycles |
| Series | AV3 |
| Voltage Rating - DC | 30 V |
| Switch Function | On-Mom |
| Operating Force | 50gf |
| Overtravel | 0.015" (0.4mm) |
| Voltage Rating - AC | 125 V |
| Electrical Life | 200,000 Cycles |
| Mfr | Panasonic Electric Works |
| Part Status | Active |
| Pretravel | 0.024" (0.6mm) |
| Features | Actuator Mounted Right Side |
| Package | Bulk |
| Differential Travel | 0.004" (0.1mm) |
| Base Product Number | AV3602619 |
Introduce
We can supply AV3602619 , send us a request quote to request AV3602619 pirce and lead time.Wisdom Mobility is a professional electronic components distributor. With 10+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number AV3602619.The price and lead time for AV3602619 depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part AV3602619.We look forward to working with you to establish long-term relations of cooperation
