FPF2300MPX

Part No FPF2300MPX
Manufacturer ON Semiconductor
Description Power Switch ICs - Power Distribution Int. Load Switch w/ 1.3A Typ Curr Limit
Lead Free Status / RoHS Status Lead Free / RoHS compliant
Availability:19741 pcs
Quantity Unit Price Ext. Price
1+ $0.4 $40
10+ $0.392 $196
100+ $0.38 $380
1000+ $0.368 $368
10000+ $0.352 $352
The above prices does not include taxes and freight rates, which will be calculated on the order pages.
Submit a Request A Quote on quantities greater than those displayed.
Target Price:(USD)
Quantity:
Total:
$0.00
  • Part No
  • Company Name
  • Contact Name
  • E-mail
  • Phone
  • Country

Specifications

Data sheet

MountSurface Mount
FeatureAuto Restart, Slew Rate Controlled, Status Flag
Radiation HardeningNo
Number of Functions1
Package / Case8-WDFN Exposed Pad
Number of Channels2
Min Input Voltage1.8V
Lifecycle StatusLAST SHIPMENTS (Last Updated: 1 week ago)
Number of Inputs1
Number of Pins8
Moisture Sensitivity Level (MSL)1 (Unlimited)
Operating Temperature-40°C~85°C TA
Min Current Limit1.1A
Output Current1.3A
Voltage - Load1.8V~5.5V
Mounting TypeSurface Mount
Weight129mg
Resistance140mOhm
Turn-Off Delay Time6 μs
PackagingTape & Reel (TR)
Terminal Pitch0.65mm
Max Input Voltage5.5V
Max Output Current1.5A
Output TypeP-Channel
Output ConfigurationHigh Side
Terminal FinishNickel/Palladium/Gold/Silver (Ni/Pd/Au/Ag)
Terminal PositionDUAL
Number of Terminations8
Supply Voltage3.3V
Height750μm
ECCN CodeEAR99
Width3mm
Lead FreeLead Free
Voltage - Supply (Vcc/Vdd)Not Required
Pbfree Codeyes
RoHS StatusRoHS Compliant
Max Supply Current1.3A
Analog IC - Other TypePOWER SUPPLY SUPPORT CIRCUIT
Input TypeNon-Inverting
Current Rating1.3A
Switch TypeGeneral Purpose
Ratio - Input:Output1:2
Rds On (Typ)75m Ω
JESD-609 Codee4
Factory Lead Time6 Weeks
Number of Outputs2
SeriesIntelliMAX™
Fault ProtectionCurrent Limiting (Fixed), Over Temperature, Reverse Current, UVLO
Length3mm
Operating Supply Voltage5.5V
Adjustable ThresholdNO
Part StatusObsolete
Published2014
Turn On Delay Time113.5 μs
InterfaceOn/Off
Base Part NumberFPF2300

Introduce

We can supply FPF2300MPX , send us a request quote to request FPF2300MPX pirce and lead time.Wisdom Mobility is a professional electronic components distributor. With 10+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number FPF2300MPX.The price and lead time for FPF2300MPX depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part FPF2300MPX.We look forward to working with you to establish long-term relations of cooperation
